SMT

HY-460BF PCB BUFFER

⭐ 1. Line Balancing and Buffering Function
Acts as a buffer between SMT machines to balance line speed and prevent bottlenecks during production.

⚡ 2. Flexible Operating Modes (FIFO / LIFO / Pass-through)
Supports multiple buffer modes, allowing flexible control of PCB flow depending on production needs.

🚀 3. Safe Storage with High Capacity
Equipped with up to 20 PCB slots and enclosed structure, ensuring safe temporary storage and smooth transfer.

YD-BBD460CDE-STACKER

⭐ 1. Automatic PCB Stacking for End-of-Line Process
Automatically collects and stacks PCBs at the end of the SMT line, reducing manual handling and improving workflow efficiency.

⚡ 2. High Capacity with Continuous Operation
Can store a large number of PCBs (typically up to 200–400 boards), supporting uninterrupted production in high-volume environments.

🚀 3. Seamless SMT Line Integration (SMEMA Compatible)
Equipped with PLC control and SMEMA interface, allowing easy connection with upstream machines and stable automated operation.

YS-LCV460FLIPPER

⭐ 1. Automatic PCB Flipping (0–180°)
Automatically flips PCBs within the SMT line, enabling double-sided processing without manual handling.

⚡ 2. Smooth and Safe Handling with Servo Control
Servo-driven flipping mechanism ensures stable movement, protecting sensitive components and maintaining product quality.

🚀 3. Seamless SMT Line Integration (SMEMA Compatible)
Works with upstream and downstream machines via conveyor system and PLC control for continuous, automated production flow.

YS-LD460 MAGAZINE LOADER

⭐ 1. Automatic PCB Loading from Magazine
Automatically loads PCBs from magazine racks into the SMT production line, reducing manual handling and improving efficiency.

⚡ 2. High Precision and Stable Operation
Equipped with PLC control, servo lifting system, and pneumatic clamping to ensure accurate positioning and smooth PCB transfer.

🚀 3. Flexible and Easy Line Integration (SMEMA Compatible)
Supports SMEMA interface and adjustable PCB sizes up to 530 × 460 mm, making it easy to integrate into various SMT lines.

HY-450ULD PCB AUTOMATIC UNLOADER

⭐ 1. Fully Automatic PCB Unloading
Automatically unloads PCBs from the SMT production line into magazine racks, reducing manual handling and improving workflow efficiency.

⚡ 2. Stable Operation with PLC Control
Equipped with PLC system, conveyor, and pneumatic pusher to ensure smooth, reliable, and damage-free PCB transfer.

🚀 3. Easy Integration with SMT Line (SMEMA Compatible)
Supports SMEMA interface for seamless connection with upstream machines, enabling continuous automated production.

YS-ULD460 MAGAZINE UNLOADER

⭐ 1. Automatic PCB Unloading to Magazine
Automatically unloads PCBs from the SMT line into magazine racks, reducing manual handling and improving production efficiency.

⚡ 2. High Precision with Servo Lifting System
Servo motor with ball screw provides precise positioning (±0.1 mm), ensuring accurate and stable PCB handling.

🚀 3. Seamless SMT Line Integration (SMEMA Compatible)
Equipped with PLC + touch screen control and SMEMA interface for smooth connection with upstream machines.

YS-NGOK ULD460 MAGAZINE NG/OK UNLOADER

⭐ 1. Automatic NG / OK PCB Sorting
Receives signals from AOI or test systems and automatically separates good (OK) and defective (NG) boards into different magazines, improving quality control.

⚡ 2. High Precision and Reliable Operation
Equipped with servo motor, ball screw system, and PLC control, ensuring accurate positioning (±0.1 mm) and stable unloading performance.

🚀 3. Efficient Dual-Magazine Handling for Continuous Production
Supports multiple magazine positions (NG + OK) and automatic unloading, reducing manual work and maintaining smooth SMT line flow.

YS-CV460 PCB DUAL CONVEYOR

⭐ 1. Dual Lane Conveyor for Higher Throughput
Dual conveyor lanes allow simultaneous PCB transfer, significantly increasing production efficiency in high-volume SMT lines.

⚡ 2. Smooth and Stable PCB Transport
Equipped with ESD belt system and anti-jam design to ensure reliable, continuous PCB movement with minimal misalignment.

🚀 3. Flexible Integration with SMT Line (SMEMA Compatible)
Supports SMEMA interface and adjustable speed (0.5–9 m/min), enabling seamless synchronization with upstream and downstream equipment.

YS-TCV460 PCB LIFTING GATE CONVEYOR

⭐ 1. Provides Safe Operator Passage Across SMT Line
Lifting gate design allows operators to easily pass through the production line without stopping PCB flow, improving workflow efficiency.

⚡ 2. Flexible Manual or Automatic Lifting System
Gate can be controlled manually or automatically, offering flexibility for different production environments and maintenance needs.

🚀 3. High Safety and Reliable Operation
Equipped with safety sensors, emergency stop, and interlock systems to ensure safe operation and protect both operators and PCBs.
